High Speed 6000 6001 6002 6003 6004 6005 Ceiling Fan Ball Bearing
Product Description
1. Grade: ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-92. OD Size: 3mm~200mm3. ID Size: 0.5mm~180mm4. Certification: ISO9001, SGS, CTI, ROHS
Product NameDEEP GROOVE BALL BEARINGMaterialChrome Steel ,Carbon steel,Sta...
- Overview
- Related Products
Product Description
1. Grade: ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-9
2. OD Size: 3mm~200mm
3. ID Size: 0.5mm~180mm
4. Certification: ISO9001, SGS, CTI, ROHS
2. OD Size: 3mm~200mm
3. ID Size: 0.5mm~180mm
4. Certification: ISO9001, SGS, CTI, ROHS
Product Name |
DEEP GROOVE BALL BEARING |
Material |
Chrome Steel ,Carbon steel,Stainless steel |
Series |
Series 6000,6200,6300,6400 ,6900,6800, etc. |
Clearance |
C2,C0,C3,C4,C5 |
Precision grade |
P0,P6,P5,P4,P2 or ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-9 |
Reference Standard |
DIN620(Germany), ANSI(America),ISO,INA, NTN, NSK,etc. |
Delivery Date |
Normally ready goods and stock within 7 days |
Used |
Electric machine, motocycle,ATM,fan,conveyor, cement mixer etc |
Item |
6000 open ZZ 2RS |
Size |
ID10 x OD26 x W8mm,0.018kg |
Radius (min.r) |
0.3mm/0.012 inch |
Basic load Rating KN |
Dynamic 4.58 C Static 1.98 C。 |
Ball complement |
NO 7 Size 4.763mm |
Max Runout Speed |
31000 r/min with grease 36000 r/min with oil |
Item |
6001 open ZZ 2RS |
Size |
ID12 x OD28 x W8mm,0.0204kg |
Radius (min.r) |
0.3mm/0.012 inch |
Basic load Rating KN |
Dynamic 5.10 C Static 2.38 C。 |
Ball complement |
NO 8 Size 4.763mm |
Max Runout Speed |
27000 r/min with grease 32000 r/min with oil |
Item |
6002 open ZZ 2RS |
Size |
ID15 x OD32 x W9mm,0.0292kg |
Radius (min.r)
|
0.3mm/0.012 inch |
Basic load Rating KN |
Dynamic 5.58 C Static 2.85 C。 |
Ball complement |
NO 9 Size 4.763mm |
Max Runout Speed |
23000 r/min with grease 27000 r/min with oil |
Item |
6003 open ZZ 2RS |
Size |
ID17 x OD35 x W10mm,0.0399kg |
Radius (min.r)
|
0.3mm/0.012 inch |
Basic load Rating KN |
Dynamic 6.00 C Static 3.25 C。 |
Ball complement |
NO 10 Size 4.763mm
|
Max Runout Speed |
21000 r/min with grease 25000 r/min with oil
|
Item |
6004 open ZZ 2RS |
Size |
ID20 x OD42 x W12mm,0.0673kg |
Radius (min.r)
|
0.6mm/0.024 inch |
Basic load Rating KN |
Dynamic 9.38 C Static 5.02 C。
|
Ball complement |
NO 9 Size 6.35mm
|
Max Runout Speed |
17000 r/min with grease 21000 r/min with oil
|
Item |
6005 open ZZ 2RS |
Size |
ID25x OD47 x W12mm,0.0781kg |
Radius (min.r)
|
0.6mm/0.024 inch |
Basic load Rating KN |
Dynamic 10.00 C Static 5.85 C。
|
Ball complement |
NO 10 Size 6.35mm
|
Max Runout Speed |
15000 r/min with grease 18000 r/min with oil
|
Item |
6006 open ZZ 2RS |
Size |
ID30x OD55 x W13mm,0.112kg |
Radius (min.r)
|
1.0mm/0.039 inch |
Basic load Rating KN |
Dynamic 10.18 C Static 6.91 C。
|
Ball complement |
NO 10 Size 6.35mm
|
Max Runout Speed |
15000 r/min with grease 18000 r/min with oil
|
Item |
6007 open ZZ 2RS |
Size |
ID35x OD62 x W14mm,0.1467kg |
Radius (min.r)
|
1.0mm/0.039 inch |
Basic load Rating KN |
Dynamic 12.47 C Static 8.66 C。
|
Ball complement |
NO 11 Size 7.938mm
|
Max Runout Speed |
11000 r/min with grease 13000 r/min with oil
|
